RCF manual Chapter 4 Technical data 11
Outputs
DO1 ..................................................... Fan-coil output 1 for fan control, relay, 230 V AC, 3 A
DO2 ..................................................... Fan-coil output 2 for fan control, relay, 230 V AC, 3 A
DO3 ..................................................... Fan-coil output 3 for fan control, relay, 230 V AC, 3 A
DO4 ................... Digital output 4 for heating/cooling, 230 V AC, max. 300 mA (3A initially).
DO5 ................... Digital output 5 for heating/cooling, 230 V AC, max. 300 mA (3A initially).
AO1, AO2 ............................ Analogue outputs, 0…10 V DC, max. 1 mA, short-circuit proof,
................................................................................... Adjustable to 2...10 V, 10...0 V, 10...2 V
For more information on inputs and outputs, see chapter Wiring.
Accessories for RCF
External temperature sensor ....................... TG-R5/PT1000, TG-UH/PT1000, TG-A1/PT1000
Presence detector ............................................................................................................ IR24-P
Change-over ...................................................................................................... TG-A1/PT1000
The accessories are available from Regin. For more detailed information concerning these
accessories, see the individual product sheet and instruction for each product, available via
www.regincontrols.com
.
