Chapter 19 BACnet signals

Analogue inputs

Object name Object ID Description Unit Writeable

RC_Actual_R.RegioRoomTemp Analog input, 0 Room temperature °C No

RC_Actual_R.RegioAIChangeOver Analog input, 1 Change-over temperature °C No

RC_Actual_R.RegioAnaIn1 Analog input, 2 Value on analogue input 1 °C No

RC_Actual_R.RegioUAnaIn1 Analog input, 3 Value on universal analogue

input 1

V No

RC_Actual_R.RegioSupplyAirTemp Analog input, 4 Supply air temperature °C No

Analogue values

Object name Object ID Description Unit Writeable

RC_Actual_R.RegioUAnaOut1 Analog value, 0 Value on universal analogue

output 1

V No

RC_Actual_R.RegioUAnaOut2 Analog value, 1 Value on universal analogue

output 2

V No

RC_Actual_R.RegioSetPAdjustment Analog value, 2 Setpoint displacement from

internal unit

°C No

RC_Actual_R.RegioPIDSetP Analog value, 3 Controller setpoint °C No

RC_Actual_R.RegioPIDOutput Analog value, 4 Controller output % No

RC_Actual_R.RegioHeatOutput Analog value, 5 Heating control % No

RC_Actual_R.RegioCoolOutput Analog value, 6 Cooling control % No

Not used in this model Analog value, 7-8 Yes

RC_Setp_R.RegioUnOccSetPHeat Analog value, 9 The room heating setpoint

when in “Economy” mode

°C Yes

RC_Setp_R.RegioUnOccSetPCool Analog value, 10 The room cooling setpoint

when in “Economy” mode

°C Yes

Not used in this model Analog value, 11

RC_Setp_R.RegioSetPOffset Analog value, 12 Setpoint displacement during

presence

°C Yes

RC_Setp_R.RegioHeatOutputManual Analog value, 13 Manual value heating output % Yes

RC_Setp_R.RegioCoolOutputManual Analog value, 14 Manual value cooling output % Yes
