A 5 - Hydraulic variants
1. Solar system with a storage tank
2. Solar system with a thermostat for storage tank heating or cooling
3. Solar system with a bypass
4. Solar system with a heating return pre-heating
5. Solar system with a thermally stratified storage tank
6. Solar system with a heat exchanger
7. Solar system with 2 collector fields (East/West)
8. Solární systém se 2 kolektorovými poli a 2 čerpadly
9. Solar system with 2 storage tanks and a zone valve
10. Solar system with 2 storage tanks and 2 pumps
11. Solar system with two storage tanks and a heat exchange pump
12. Solar system with a pool
13. Solar system with a pool and storage tank
14. Solar system + cooling 1
15. Solar system + cooling 2
16. Solar system + cooling 3
17. Solar system + solid-fuel boiler
18. Solar system + zone valve + thermostat
19. One differential ∆T controller and 1 thermostat (no solar functions)
20. 2 temperature difference controllers 2×∆T (no solar functions)
1
3
5
2
4
7
10
13
6
8
9
11 12
19
(ΔT-Controller)
20
(2x ΔT-Controller)
ΔT 2xΔT
14
15
16
17
18
