REMdevice t3 User Manual

Instruction Manual
Radio control devices T3, T5 and T7.
version 1.4 Genn. 10
Attention: the frequency changing operation must be carried out
with the transmitter programmed in medium or normal power
operating mode, this operation is not possible if the “low power
start” function has been activated in the transmitter. See the chapter
“Programming the transmitter functions (page 22).
Tables of frequencies
Band 869.700 – 870.000 MHz
CH1
869.7125
CH2
869.7375
CH3
869.7625
CH4
869.7875
CH5
869.8125
CH6
869.8375
CH7
869.8625
CH8
869.8875
CH9
869.9125
CH10
869.9375
CH11
869.9625
I - Band 433.050 – 434.025 MHz
CH1
433.0625
CH2
433.0875
CH3
433.1125
CH4
433.1375
CH5
433.1625
CH6
433.1875
CH7
433.2125
CH8
433.2375
CH9
433.2625
CH10
433.2875
CH11
433.3125
CH12
433.3375
CH13
433.3625
CH14
433.3875
CH15
433.4125
CH16
433.4375
CH17
433.4625
CH18
433.4875
CH19
433.5125
CH20
433.5375
CH21
433.5625
CH22
433.5875
CH23
433.6125
CH24
433.6375
CH25
433.6625
CH26
433.6875
CH27
433.7125
CH28
433.7375
CH29
433.7625
CH30
433.7875
II - Band 434.050 – 434.790 MHz
CH31
434.0625
CH32
434.0875
CH33
434.1125
CH34
434.1375
CH35
434.1625
CH36
434.1875
CH37
434.2125
CH38
434.2375
CH39
434.2625
CH40
434.2875
CH41
434.3125
CH42
434.3375
CH43
434.3625
CH44
434.3875
CH45
434.4125
CH46
434.4375
CH47
434.4625
CH48
434.4875
CH49
434.5125
CH50
434.5375
CH51
434.5625
CH52
434.5875
CH53
434.6125
CH54
434.6375
CH55
434.6625
CH56
434.6875
CH57
434.7125
CH58
434.7375
CH59
434.7625
CH60
434.7875
REMdevice
®
- ITALY page 21 of 28

REMdevice t3 Specifications

Operating Environment

operative frequency range 1	869.700 – 870.000 MHz
operative frequency range 2	433.050 – 434.790 MHz
operating and storage temperature	-20°C / +70°C

Power

power supply option 1	12-24Vdc 1, 0A
power supply option 2	24-48Vac/dc 50-60 Hz 0.4A
power supply option 3	48-115Vac/dc 50-60 Hz 0.4A
power supply option 4	115-230Vac/dc 50-60 Hz 0.2A

Receiver Specifications

command relay contacts capacity	4A 115 Vac.
stop relay contacts capacity	4A 115 Vac.
range of control	100 mt.

Transmitter Specifications

radio frequency output power	1 to 10 mW
supply voltage	3.6 Vdc.
power consumption range	13.5 mA to 24 mA
battery	integrated lithium ions 3.6V
working autonomy	up to 1200 hours (20°C)
low battery warning	at 30 hours left

Dimensions and Weight

container dimensions	158×90×75 mm (L×H×D)
watertight case Ruby-T7 dimensions	169×266×89 mm (L×H×D)
watertight case ECOBOX dimensions	124×176×45 mm (L×H×D)
transmitter dimensions	176x85x37 mm (L×H×D)
transmitter weight	350 g
