2010 Release
E-5
Point E
EE’ support
Anti-roll
bar tie-rod
Support
strut
Pivot
Damper system
z
-
axis
y-axis
Point E’ bolt
Pivot holde
r
Calipe
r
Point F’:
Pivot to pivot
holder mounting
ball joint
Roller bearing
Disk
Hub
