10A-6
ENGINE AND CYLINDER BLOCK ASSEMBLY
Crankshaft seal at timing end Removal - Refitting
K9K
10A
a Fit the protector equipped with the crankshaft seal
onto the spacer, taking care not to touch the cranks-
haft seal.
a Fit the cover (10) and the nut (11) (positioning the
thread (12) of the nut towards the outside of the en-
gine).
a Screw on the nut until the cover touches the spacer.
20770
20769
20768
20767
