Renault K4M - Preheating; Pre;Postheating Unit: Removal - Refitting

13C-1
PREHEATING
Pre/postheating unit: Removal - Refitting
F9Q or K9K
13C
REMOVAL
I - OPERATION FOR REMOVAL OF PART
CONCERNED
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Disconnect the battery (see Battery : Removal -
Refitting) (80A, Battery).
a Remove:
-the front wheels (see Wheel: Removal - Refitting)
(35A, Wheels and tyres),
-the front section of the front wheel arch liners (see
Front wheel arch liner: Removal - Refitting)
(55A, Exterior protection),
-the front bumper (see Front bumper: Removal -
Refitting) (55A, Exterior protection),
-the air resonator (see 12A, Fuel mixture, Air reso-
nator: Removal - Refitting, page 12A-1) .
a Remove the air resonator support nuts (1) .
a Move aside the air resonator support.
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Disconnect the pre-postheating unit connector (2) .
a Remove:
- the pre-postheating unit nut (3) ,
- the pre/postheating unit.
F9Q or K9K, and 830
136669
K9K
135505
