13C-2
PREHEATING
Pre/postheating unit: Removal - Refitting
F9Q or K9K
13C
a Disconnect the pre-postheating unit connector (2) .
a Remove:
-the pre-postheating unit nut (3) ,
-the pre/postheating unit.
REFITTING
I - REFITTING OPERATION FOR PART
CONCERNED
a Refit the pre-postheating unit.
a Connect the pre-postheating unit connector.
II - FINAL OPERATION
a Fit the air resonator support.
a Refit the nuts of the air resonator support.
a Refit:
-the air resonator (see 12A, Fuel mixture, Air reso-
nator: Removal - Refitting, page 12A-1) ,
- the front bumper (see Front bumper: Removal -
Refitting) (55A, Exterior protection),
- the front section of the front wheel arch liners (see
Front wheel arch liner: Removal - Refitting)
(55A, Exterior protection),
- the front wheels (see Wheel: Removal - Refitting)
(35A, Wheels and tyres).
a Connect the battery (see Battery : Removal - Refit-
ting) (80A, Battery).
F9Q
136183
K9K, and 830
