12A-33
FUEL MIXTURE
Injector holder shim: Removal - Refitting
K4M
12A
III - FINAL OPERATION
a Refit:
-the « injector rail - injector » assembly (see 17B,
Petrol injection, Injector rail - Injectors: Remo-
val - Refitting, page 17B-19) ,
-the inlet manifold (see 12A, Fuel mixture, Inlet
manifold: Removal - Refitting, page 12A-23) ,
-the throttle valve (see 12A, Fuel mixture, Throttle
valve: Removal - Refitting, page 12A-17) .
a Refit the dipstick guide.
a Torque tighten the dipstick guide tube bolts (10
N.m).
a Refit the dipstick.
a Refit:
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-7) ,
-the scoop under the scuttle panel grille (see Scoop
under scuttle panel grille: Removal - Refitting)
(56A, Exterior equipment),
-the scuttle panel grille (see Scuttle panel grille:
Removal - Refitting) (56A, Exterior equipment),
-the windscreen wiper arms (see Windscreen wi-
per arm: Removal - Refitting) (85A, Wiping -
Washing),
-the front section of the front right-hand wheel arch
liner (see Front wheel arch liner: Removal - Re-
fitting) (55A, Exterior protection),
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres),
-the engine cover.
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
K4M, and 858 or 866
