13B-29
DIESEL INJECTION
Leak flow from high-pressure pump: Check
K9K, and 832
13B
a Connect the diesel injector fuel return rail to the high
pressure pump.
a Refit:
-the injector rail protector cover,
-the injector rail protector cover nut,
-the injector rail protector cover bolt.
a Clip on the injector rail protector cover.
a Fit the damper valve wiring.
a Clip the damper valve wiring onto the injector rail
protector cover.
a Connect:
-the camshaft position sensor connector,
-the damper valve connector,
-the intercooler outlet air pipe on the damper valve.
a Torque tighten the intercooler air outlet pipe clip
on the damper valve (5.5 N.m).
a Refit:
-the turbocharger air outlet pipe (see 12B, Turbo-
charging, Intercooler air inlet pipe: Removal -
Refitting, page 12B-41) ,
-the engine cover.
