14A-17
ANTIPOLLUTION
Intercooler: Removal - Refitting
K9K, and 836
14A
a Fit without tightening the bolts of the timing end ex-
haust gas recirculation assembly support on the ex-
haust gas recirculation assembly.
a Connect the coolant hose to the exhaust gas cooler.
a Refit:
-the new coolant hose clip between the exhaust gas
cooler and the exhaust gas recirculation solenoid
valve,
-the exhaust gas pressure sensor,
-the exhaust gas pressure sensor clip.
a Fit the exhaust gas recirculation assembly on the cy-
linder head equipped with the exhaust gas recircula-
tion assembly mounting.
a Tighten:
-the bolts of the exhaust gas recirculation assembly
on the cylinder head,
-the bolts of the exhaust gas recirculation assembly
mounting on the cylinder head,
-the bolts of the exhaust gas cooler on the exhaust
gas recirculation support,
-the bolts of the exhaust gas recirculation assembly
support on the exhaust gas recirculation assembly.
a Remove:
-the bolts of the exhaust gas recirculation assembly
on the cylinder head,
-the bolts of the exhaust gas recirculation assembly
mounting.
a On the workbench, torque tighten the following:
-the exhaust gas cooler bolts on the exhaust gas
recirculation mounting (12 N.m),
-the bolts of the exhaust gas recirculation as-
sembly mounting (12 N.m).
III - FINAL OPERATION
a Refit:
-the exhaust gas recirculation assembly (see 14A,
Antipollution, Exhaust gas recirculation as-
sembly: Removal - Refitting, page 14A-18) ,
-the exhaust gas recirculation rigid pipe (see 14A,
Antipollution, Exhaust gas recirculation rigid
pipe: Removal - Refitting, page 14A-30) ,
- the engine undertray,
- the engine cover.
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
a Fill and bleed the cooling system (see 19A, Coo-
ling, Cooling circuit: Draining - Refilling, page
19A-17) .
Note:
The exhaust gas cooler must remain mobile in
relation to the exhaust gas recirculation support
so that it can be adjusted correctly.
