14A-37
ANTIPOLLUTION
Exhaust gas recirculation rigid pipe: Removal - Refitting
K9K, and 836
14A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Remove:
-the engine cover,
-the engine undertray bolts,
-the engine undertray.
a Undo:
-the air filter unit air outlet pipe clip (1) on the air fil-
ter unit,
-the air filter unit air outlet pipe clip (2) on the turbo-
charger air inlet pipe.
a Remove the air filter unit air outlet pipe.
a Unclip the turbocharging pressure regulation sole-
noid valve hose from the turbocharger air inlet pipe
at (3) .
a Remove the turbocharger air inlet pipe bolt from the
exhaust gas recirculation assembly (4) .
