NU650_12_G3-FRA.qxd 9/12/04 11:22 Page 3.23
TRAFIC - NU 650-12 X83
C:\Documentum\Checkout\NU650-12_T3-ENG.win 17/12/2004 7:21
-page23
3.23
REAR BENCH SEATS: REMOVING/FITTING
Bench seats 1 and 2 are removed
and fitted in the same way.
Bench seat 1 can be fitted in the first
or last row.
Bench seat 2 canonlybefittedin
the first row.
Depending on the
vehicle, it is forbidden to
switch bench seats 1 and
2 around.
Removal
First, release the side seat belts by
unlocking them from their casing.
- Press latches 3 on either side of the
bench seat then pull it forwards
(movements A and B);
- lift it (movement C);
- move the bench seat towards the
rear of the vehicle to release the
rear anchorage (movement D);
- lift the bench seat (movement E);
- move the bench seat once more
towards the rear (movement F)to
release the front anchorage points;
- remove the bench seat.
