TRANSPORTING OBJECTS (continued)
Fit separation net A behind the
rear seats
Inside the vehicle on each side:
Upper mounting:
- lift and hold cover 1 to access the
mounting hole,
- insert upper rod 2 of the net into
largest section 3 of the hole,
- slide the rod into lower section 4
of the hole.
Lower mounting:
-attachhook5 of the luggage strap
onto ring 8 at the base of the bench
seat,
- adjust the luggage net so that it is
taut.
Removal
Loosen the strap. Detach the belts.
Checkthattheendofrod
2 is resting against the
metalpartofthecover
and not the plastic part.
