RZ/A2M SUB Board RTK79210XXB00000BE 1. Overview

R20UT4398EJ0100 Rev.1.00 1-9

2018.10.11

1.7 Memory Mapping

Figure 1.6 shows the RZ/A2M memory mapping of RTK79210XXB00000BE.

Logic address

RZ/A2M logic space

RTK79210XXB00000BE

Memory mapping

H'0000 0000

CS0 space: 64 MBybes

H'0400 0000

CS1 space: 64 MBytes

H'0800 0000

CS2 space: 64 MBytes

H'0C00 0000

CS3 space: 64 MBytes

SDRAM (64 MBytes)

H'1000 0000

CS4 space: 64 MBytes

H'1400 0000

CS5 space: 64 MBytes

H'1800 0000

Other: 128 MBytes

H'2000 0000

SPI multi I/O bus space: 256 MBytes

Serial flash memory (64 MBytes)

H’2400 0000

H'3000 0000

HyperFlash space: 256 MBytes

HyperFlash (64 MBytes)

H’3400 0000

H'4000 0000

HyperRAM space: 256 MBytes

HyperRAM (8 MBytes)

H’4080 0000

H'5000 0000

OctaFlash space: 256 MBytes

H'6000 0000

OctaRAM space: 256 MBytes

H'7000 0000

Reserved (cannot be used)

Reserve(cannot be used)

H'8000 0000

Large-capacity internal RAM: 4 MBytes

H'8040 0000

Other: 2044 MBytes

H'FFFF FFFF

Figure 1.6 RZ/A2M Memory Mapping
