3.2.2 Switch Functions
RTK79210XXB00000BE is equipped with six switches.
Figure 3.2.3 shows the mounted switch layout diagram, Table 3.2.2 lists the mounted switches, and Table 3.2.3
provides the explanation of DIP switch functions.
Figure 3.2.3 RTK79210XXB00000BE Mounted Switch Layout Diagram
SW5 SW4 SW3 SW2
C side top view
SW6
ON
1 2 3 4 5 6 7 8 9 10
SW1
1 3
