RZ/A2M SUB Board RTK79210XXB00000BE 3. Operating specifications
R20UT4398EJ0100 Rev.1.00 3-2
2018.10.11
Figure 3.1.2 RTK79210XXB00000BE Connector Layout Diagram (S Side Top View)
CN10: SD card slot
CN12: USB Series A
Port
