Renesas RZ/A2M

RZ/A2M SUB Board RTK79210XXB00000BE 3. Operating specifications
R20UT4398EJ0100 Rev.1.00 3-17
2018.10.11
Table 3.1.13 LVDS Back Light Connector (CN16) Pin Layout Table
Pin
Signal name
1
VLED (5V) (+5V)
2
VLED (5V) (+5V)
3
DIMMER (Brightness Adjust) (connects to +3.3V via 10kΩ resistor)
4
ENABLE (connects to +3.3V via 10kΩ resistor)
5
GND (Vss)
6
GND (Vss)
