RZ Family / RZ/G, RZ/A Series 2. Functional Specifications
R01UH0990EJ0101 Rev.1.01 Page 30 of 83
Jul 28, 2022
Table 2.2 List of Pin Function Selection Used on Each Module Board (6/18)
Pin
Location
Pin Name
RZ/G2UL
Pin Function
RZ/A3UL
Pin Function
RZ/Five
Pin Function
Description
SMARC
Pin No.
SMARC
Pin Name
N2
P4_2/
ET0_RX_ERR/
RSPI1_MISO/
MTIOC8C/
MTIOC3A
RSPI1_MISO
RSPI1_MISO
RSPI1_MISO
Carrier Board Connector, connected
to PMOD0 connector (J1)
P57
SPI1_DIN
AD20
P10_0/
ET1_RXD3/
SSI0_BCK/IRQ4/
MTIOC6A/IRQ2
ET1_RXD3
ET1_RXD3
ET1_RXD3
Ethernet PHY_1 (IC23)
—
—
AD18
P10_1/
ET1_RX_ERR/
SSI0_RCK/
SSI3_BCK/
MTIOC6B
ET1_ERR
ET1_ERR
ET1_ERR
Unused
—
—
AC20
P10_2/
ET1_MDC/
SSI0_TXD/
SSI3_RCK/
MTIOC6C
ET1_MDC
ET1_MDC
ET1_MDC
Ethernet PHY_1 (IC23)
—
—
AE21
P10_3/
ET1_MDIO/
SSI0_RXD/
SSI3_TXD/
USB1_VBUSEN/
MTIOC6D
ET1_MDIO
ET1_MDIO
ET1_MDIO
Ethernet PHY_1 (IC23)
—
—
AC19
P10_4/
ET1_LINKSTA/
ADC_TRG/
SSI3_RXD/
USB1_OVRCUR
ET1_LINKSTA
ET1_LINKSTA
ET1_LINKSTA
Ethernet PHY_1 (IC23)
—
—
A10
P11_3/SSI0_RXD
/POE10#/
SCI1_CTS#/
RTS#/
RSPI2_SSL/
DISP_CLK
DISP_CLK
DISP_CLK
P11_3
Connected to 45pin FFC/FPC
connector (CN5)
Note: Unused in case of
RZ/Five
—
A10
B10
P11_2/SSI0_TXD
/POE8#/
SCI1_SCK/
RSPI2_MISO/
DISP_DATA0/
SCIF1_TXD
DISP_DATA0
DISP_DATA0
P11_2
Connected to 45pin FFC/FPC
connector (CN5)
Note: Unused in case of
RZ/Five
—
B10
A11
P13_1/
SCIF0_RXD/
CAN0_TX/
MTIOC4B/
USB1_OVRCUR/
DISP_DATA1/
SCIF1_RXD
DISP_DATA1
DISP_DATA1
P13_1
Connected to 45pin FFC/FPC
connector (CN5)
Note: Unused in case of
RZ/Five
—
A11
A14
P16_0/
SCIF1_CTS#/
CAN1_RX_DATA
RATE_EN/
SCI0_CTS#/
RTS#/
DISP_DATA10
DISP_DATA10
DISP_DATA10
P16_0
Connected to 45pin FFC/FPC
connector (CN5)
Note: Unused in case of
RZ/Five
—
A14
