RZ Family / RZ/G, RZ/A Series 4. Parallel to HDMI Converision Board
R01UH0990EJ0101 Rev.1.01 Page 71 of 83
Jul 28, 2022
3. Rotate down the actuator until firmly closed.
NOTE
The PFC must be fully inserted in the connector. If not fully inserted, the actuator will not close property.
Should this be the case, lift up the actuator and repeat the process (starting with Step 1 above)
Figure 4.5 How to install the 50mm FPC (3)
4. FPC Removal
1) Lift up the actuator.
2) Carefully remove the FPC
Figure 4.6 How to remove the 50mm FPC

Renesas RZ Series Specifications

General

USB	USB 2.0, USB 3.0
Operating Temperature	-40°C to +85°C
Typical Operating Current	Varies by model
Operating Frequency	Varies by model
Memory	DDR3, DDR4
Memory Interface	DDR3, DDR4
Video Codec	H.264
Ethernet	10/100/1000 Ethernet
I/O Interfaces	UART, SPI, I2C, CAN
Package	BGA
Core	Cortex-A, Cortex-M
