Renfert Silent TS2 - Start-Up Threshold; Shut-Off Delay

- 12 -
 Press menu key (30) 3x
Ƈ The dust drawer symbol (33) blinks
Ƈ The set sensitivity level is shown.
 &KDQJHWKHOHYHOXVLQJWKHEXWWRQV
Ƈ IXOO
Ƈ ORZ¿OOOHYHO
 Press enter button (40).
5.3.4 Start-Up Threshold
The start-up threshold, the point at which the connected electrical appliance opens the suction hose,
can be individually adjusted for each hose.
 Press menu key (30) 4x
Ƈ The start-up threshold symbol (34) blinks.
Ƈ The letters A and B blink.
 Press the suction hose button (39) of the suction which is to be adjusted
Ƈ The letter of the selected hose is indicated.
Ƈ The display shows „OFF“.
 Switch the electrical appliance off. Units equipped with a stand-by mode should be switched to
stand-by (e.g. in the case of a hand piece, only switch the controller on without activating the hand
piece).
 Press the enter button (40)
Ƈ The display shows “ON”.
 Switch the electrical appliance on, e.g. activate the hand piece at the speed at which you require the
suction hose to open.
 Press the enter button (40).
 Select the next suction hose which you would like to adjust, or quit this menu by pressing the menu
key (30).
Before selecting a suction hose, press the /
/
/
/
/
buttons together and the start-up threshold on
both hoses will return to the factory set parameter (8 W).
5.3.5 Shut-Off Delay
Shut-off delay = the amount of time between switching the connected electrical appliance off and the
closure of the respective suction hose (= pinch valve).
Two types of shut-off delay times can be distinguished, each of which can be set independently of one
DQRWKHU
 2QO\RQHRIWKHWZRVXFWLRQKRVHV$25%LVRSHQ
Set the time, from when the pinch valve in the suction hose closes and the suction turbine shuts off
(e.g. for targeted suction of residue dust)
MENU
A
B
OFF
ON
B
resetdefault
Fig. 13
30
40
34
39
MENU
A
B
OFF
ON
A
B
resetdefault
Fig. 14
30
40
EN
