Renfert Silent TS2 - Technical Data

- 18 -
Error Code Cause / Meaning Corrective Action
Err22 Suction hose A blocked or defect. Make sure the suction line and pinch valve in the
suction hose are not blocked.
Err23 Suction hose B blocked or defect.
Err26 Suction hose A or B permanently open. Make sure the pinch valve on the suction hose is not
blocked that the pinch valve membrane is not defect.
Check to ensure that the pinch valve is assembled
correctly.
Err51 Error occurred whilst adjusting the start-up
threshold.
Cancel the adjustment of the start-up threshold using
WKHPHQXNH\¿JDQGHQWHUWKHUHTXLUHG
setting afresh as described in Chapter 5.3.4
8. Technical Data
Working Voltage 230 V 120 V
Permissible mains voltage 220 - 240 V 120 V
Mains frequency 50/60 Hz 60 Hz
Suction turbine power *) 1400 W 1400 W
max. connecting power *) 2000 W 360 W
Total connected power *) 3400 W 1800 W
Mains input fuse 2x 15 A (T)
max. connection pressure 8 bar
[116 psi]
min. connection pressure 4,5 bar
[65 psi]
/S$DWPD[YROXPHÀRZ 59 dB(A)
Number of suction hoses 2
9ROXPHÀRZPD[SHUVXFWLRQKRVH 3300 l/min
Vacuum pressure, max 20 kPa
[2,9 psi]
)LQHSDUWLFOH¿OWHU
Filter surface area ca. 0.8 m²
[ca. 1240 sq inch]
FIlterquality Class M according to EN60335-2-69
Fill volume, dust bag ca. 7,5 l
[2 US Gallonen]
Dimensions (height x width x depth) 595 x 225 x 565 mm
[23,4 x 8,8 x 22,2 inch]
Weight (empty) ca. 27 kg
[ca. 59,5 lbs]
6XFWLRQ¿WWLQJV
Internal 45 mm
[1,77 inch]
External 50 mm
[1,97 inch]
*) Working voltage power
**) Sound pressure levels according to EN ISO 11202
EN
