Renishaw NC4 Installation And Maintenance Guide

10
Dimensions – transmitter and receiver
Ø30 (Ø1.18)
Ø26 (Ø1.02)
24 (0.95) across flats
35
(1.38)
19
(0.75)
5.4 (0.21)
7.5
(0.3)
1.0 (0.039)
4.0 (0.16)
3.0 (0.12)
A
B
C
D
B
A
9.5
(0.37)
9.5
(0.37)
1.0
(0.039)
7.5 (0.3)
A = Mounting holes, 2 off, M3 x 0.5 P x
8 mm (0.32 in) deep
B = Dowel holes, 2 off, Ø2 mm x
8 mm (0.32 in) deep
C = Pneumatic push-fit connector,
1 off, Ø3 mm (Ø0.12 in) plastic
pipe
D = Supply cable, 1 off, Ø6 mm
(Ø0.24 in)
E = Passive seal vent. Do not cover.
F = Blanking screw. Do not disturb.
4.0 (0.16)
View from bottom
of transmitter and
receiver units
Dimensions in mm (in)
E
F
