Renishaw NC4 Installation And Maintenance Guide

11
Dimensions – machining details for a typical mounting
Dimensions in mm (in)
9.5 (0.37) 9.5 (0.37)
7.5 (0.30)
2 × Ø3.5 (0.14)
2 × Ø2.0 (0.08)
Ø13.5
(0.53)
1.0
(0.04)
4.0
(0.16)
7.5
(0.30)
Ø6.2
(0.24)
Ø6.2
(0.24)
1.0
(0.04)
4.0
(0.16)
3.0
(0.12)
