Renishaw NC4 Installation And Maintenance Guide

65
Servicing – NC4 fixed system
M4 rotation holding screw (2 off)
Disc spring (2 off)
Plain washer (2 off)
NC4 transmitter
or receiver unit
Mounting block
Push fit/release
pneumatic fitting
M3 holding screw (2 off)
Air pipe
Electrical cable
Fixed system housing
Cover plate
M3 cover plate screws (4 off)
Disc spring
showing correct
orientation when fitted
Approx.
100 mm
(4 in)
Rotation adjuster screws
