72
Servicing – air regulator unit
A
B
4. Fit the new components to the
regulator body.
5. Refit the regulator head and tighten
to 7.7 Nm (5.7 Ibf.ft).
6. Switch on the air supply and set
the pressure as described in
“Setting the air pressure” on
page 34.
NOTE: Items shown within dotted
boxes A and B are included in the air
filter service kit obtainable from
Renishaw (see the parts lists on
page 78).
