IF.UG.IM_R1
Select Ack [N] Alarms to acknowledge all unacknowledged alarms where N indicates the current
number of unacknowledged alarms.
Select Reset Faults to issue a reset command to all modules. This will reset Pump Faults, Valve
Faults, Interlock First-Outs, Config Error First-Outs, and other resettable faults. A small red dot will
be visible (blinking or solid) on a final element device when a reset is required, or the device is not
ready.
The Line 1/Line 2/Global Interlocks status indicator indicates when an interlock is active.
The E-Stop status indicator indicates the status of the E-Stop safety system.
The All Interlocks Bypassed status indicator indicates whether or not the All Interlocks bypassed
function has been activated. All Interlocks Bypassed is an engineering function that can only be
activated from the PLC itself and has no method for setting from the HMI.
Select Global Parameters to show an interactive list of current Global Parameters.
Select Report Records to show an interactive list of current Report Records. This selection is only
visible when an Operation is active.
Select OP Parameters to show an interactive list of current Operations Parameters. This selection is
only visible when an Operation is active.
Select UP Parameters to show an interactive list of current Unit Procedure Parameters. This
selection is only visible when a Unit Procedure is active.
Select External Parameters to show an interactive list of current External Batch Parameters. This
selection is only visible when External Batch Mode is active.
Select PAUSE to pause a running process, and Select RESUME to resume a paused process.
Select Load to load a process recipe.
Select Start to run a loaded process recipe.
Select Hold to pause a running process.
Select Restart to run a held (paused) process.
Select Abort to terminate a running process.
Select Stop to stop a running process in an orderly shutdown.
Select Reset to clear Batch parameter settings.
Select Login to log into the HMI using a pre-configured user account name and password.
Select Logout to log out from the HMI.
Select Password to change the password for the logged in user.
