Temperature, Operating: 0° to 40°C (32° to 104°F)
Temperature, Storage: –25° to 65°C (–13° to 149°F)
Humidity (non-condensing): 10% to 90%
Altitude: Less than 2000 m
Pollution Degree: Pollution Degree 2
Compliance: (For ETL Mark):
UL 61010-1, CAN/CSA C22.2 No. 61010-1
(For CE Mark):
EN61010-1 (EU Low Voltage Directive) and
EN61326 (EU EMC Directive)
RoHS
KMPi Specifications
Output
Speed:
All models 0.1 to 650 rpm
Torque output, max.
All models 520 oz-in (37.4 kg • cm)
1560 oz-in Starting
Speed regulation:
All models Line ±0.1% F.S.
Load ±0.1% F.S.
Drift ±0.1% F.S.
Display:
All models 128 x 64 LCD w/ LED Backlight
Remote outputs:
All models Voltage speed output
(0-10V DC @ 1 kΩ min)
All models Current speed output
(0-10 mA @ 0-600Ω)
All models Tach output
(100 to 6500 Hz, 50% duty cycle, 10 Hz/rpm)
All models Motor running output
(N.O. & N.C. contact closure, 1A @ 28V DC)
Input
Supply voltage limits:
All models 90 to 260 Vrms @ 50/60 Hz
(Universal Input)
Current, max.:
All models 4.5A @ 115 Vrms, or 2.6A @ 230 Vrms
Remote Inputs:
All models START/STOP, CW/CCW, PRIME
(Contact closure)
All models Voltage input (0-10V DC @ 10 kΩ),
±50V common mode range
