ResMed S9 Series Clinical Guide

3
English
Air filterDC power inlet
SD card slot
Module/Adapter port
Air outlet
S9 at a glance
The S9 system comprises the following elements:
• S9 device
• SlimLine air tubing
• 90W power supply unit
• S9 travel bag
• SD card
• S9 SD card protective folder.
Optional components include:
• H5i heated humidifier
• Standard air tubing
• S9 Wireless Module—compatible only with the S9 AutoSet and S9 Elite
• S9 Oximeter Adapter—compatible only with the S9 AutoSet and S9 Elite
• 30W power supply unit (does not support H5i)
• Power Station II battery pack
• DC/DC Converter 24V/90W.
Traveling with the S9
When the patient travels with the S9 only:
• Advise the patient to pack the SlimLine or Standard air tubing as the ClimateLine or ClimateLine
MAX
heated air tubing is not designed to connect directly to the S9 device.
• Advise the patient to purchase and travel with the approved power cord for the region where they will
be using the S9 device.
• ResMed confirms that the S9 Series meets the Federal Aviation Administration (FAA) requirements
(RTCA/DO-160F, section 21, category M) for all phases of air travel.
368220.indb 3 6/09/2011 9:21:16 AM

ResMed S9 Series Specifications

General

Data Storage	SD card
Device Type	CPAP Machine
Pressure Range	4 to 20 cm H2O
Sound Level	24 dB
Power Supply	100-240V AC, 50/60Hz
Therapy Modes	CPAP, VPAP ST, VPAP Auto
Altitude Adjustment	Yes
Operating Temperature	+41°F to +95°F (+5°C to +35°C)
Operating Humidity	10% to 95% non-condensing
AC Voltage	100-240V AC
Humidifier	optional
Ramp	Yes
