relay allocation
sensor allocation
sen.1 sen.2 sen.3 sen.4 sen.5 sen.6 sen.7 sen.8 sen.9 sen.10 V40
Tkol
Tspu
DVGW
Th 1
Tby
T-WT
T1DT5
Th 2
Tsp2u
T2-DT5
Tsp3u Tsp4u
Th 7
T1-DT8
Th 8
T2-DT8
Th 9
T1-DT9
T1 WMZ
Th 10
T2-DT9
T2 WMZ
WMZ
relay 1 relay 2 relay 3 relay 4 relay 5 relay 6 relay 7
solar pump st1 solar pump st2
func. bl. 1
HSE
bypass
par. relay
ext. HE
solar pump st3 solar pump st4
func. bl. 4
store load.
func. bl. 5
message rel.
AH suppress.
System 7 variant 2
S1
S5
S2
S4
R2
R4
S6
R1
R5
sensor denomination
Tcol temperature-collector
Tcol2 temperature-collector 2
Tstb temperature-store 1 base
Tst2b temperature-store 2 base
Tst3b temperature-store 3 base
Tst4b temperature-store 4 base
T-HE temperature-heat exchanger
Tby temperature-bypass
HSE temperature- protection against legionella
Th 1-10 temperature-thermostat 1-10
T1-DT5-9 temperature- DT5-9 high
T2-DT5-9 temperature- DT5-9 low
T1-AH-HC temperature- afterheating-heating circuit
T2-AH-HC temperature- afterheating-heating circuit
HC T-FL temperature- heating circuit ow
HC T-outd. temperature- heating circuit outdoors
HC RTA11 heating circuit remote control
T1 WMZ temperature- ow heat quantity measure-
ment
T2 WMZ temperature- return heat quantity
measurement
WMZ owmeter
Abbreviations - sensors
sensor location
1 DeltaSol E
2 DeltaSol E
3 DeltaSol E
4 DeltaSol E
5 DeltaSol E
6 DeltaSol E
7 DeltaSol E
8 DeltaSol E
9 DeltaSol E
10 DeltaSol E
11 Flow HC
12 1. HKM (S1)
13 1. HKM (S2)
14 1. HKM (S3)
15 1. HKM (S4)
16 1. HKM (S5)
sensor location
17 1. HKM (S6)
18 Flow 1. HKM
19 2. HKM (S1)
20 2. HKM (S2)
21 2. HKM (S3)
22 2. HKM (S4)
23 2. HKM (S5)
24 2. HKM (S6)
25 Flow 2. HKM
26 3. HKM (S1)
27 3. HKM (S2)
28 3. HKM (S3)
29 3. HKM (S4)
30 3. HKM (S5)
31 3. HKM (S6)
32 Flow 3. HKM
Sensor allocation
Sensors 1-10 are the sensors connected to the controller.
Sensors 12-32 are the sensors connected to the addition-
ally connected heating circuit modules.
Sensors 11, 18, 25 and 32 show the calculated ow set
temperature respectively.
