Resol DeltaSol E User Manual

GND
S1 CS10 S8 S10 V40
R7-A R7-M R7-R
R6 R5 R1 R2 R3 R4
S9 S7 S6 S5 S4 S3 S2
Sensors
Bus
VBus
floating relay
semiconductor relay
OK / Set
R1-R6
1 (1) A (100 ... 240) V~
4 (1) A (100 ... 240) V~
R7
Netz / Mains
100 ... 240 V~
50-60 Hz
T4A
IP 20
L' LN
Vor Öffnen Gerät spannungslos
schalten!
Isolate mains before removing cover!
Masse-Sammelklemme benutzen
Use the ground common terminal block
Neutralleiter.
Sammelklemme benutzen!
Use neutral conductor
collective block
Erdungsleiter-Sammel-
klemme benutzen!
Use ground common
terminal block!
GND
PWMA PWMB
PWMC
GND
GND
12
34 5
6
Made in Germany
DeltaSol
®
E
V2
VBus
®
neutral conductor-
common terminal block
ground terminal-
common terminal block
mains terminals
fuseT4 A
(supply to all relays)
sensor terminals
load terminals
sensor-
ground-common terminal block
ATTENTION!
ESD damage!
Electrostatic discharge can lead to damage
to electronic components!
ÎTake care to discharge properly
before touching the inside of the
device! To do so, touch a grounded
surface such as a radiator or tap!
WARNING!
Electric shock!
Upon opening the housing, live parts are
exposed!
ÎAlways disconnect the controller
from power supply before opening
the housing!
Note:
Connecting the device to the power supply must
always be the last step of the installation!
1.2 Electrical connection
1.2.1 Overview of electrical connections
DeltaSol
®
E
© RESOL 20160310 DeltaSol_E_V2.monen.indd
5 |
