In the „Max speed“ channel, a maximum pump speed can
be adjusted for the corresponding output.
Maximum speed
Expert/Relay/Max speed1 (...3)
Adjustment range: 30 … 100%
Factory setting: 100 %
Language
Expert/Language
factory setting: „Deutsch“
In the submenu „language“, different languages are available
(German, English, French, Castellano, Italian).
Pump speed control
Expert/Relay/Signal1 (...3)
Selection: On/Off, Puls, PSol, Phea, 0-10V
Factory setting: Puls
With this parameter, the pump control type can be ad-
justed.
The following types can be selected:
Adjustment for standard pump without speed control
• On/Off (pump on / pump off)
Adjustment for standard pump with speed control
• PULS (pulse packet control via semiconductor relay)
Adjustment for high efciency pump (HE pump)
• PSOL (PWM prole for a high-efciency solar pump)
• PHEA (PWM prole for a high-efciency heating pump)
• 0-10V (speed control via a 0-10V signal)
In order to reduce the number of switching processes for
high-efciency pumps, the controller is equipped with a re-
lay overrun function that automatically comes into effect
when the speed control signal is not issued by the relay
itself (PUM = PSOL or PHEA). The corresponding relay will
then remain switched on for an hour after the switch-off
conditions are fullled.
WARNING! Electric shock!
During the overrun time, the relay symbol
disappears from the display and the pump
is inactive, but the relay is still energised!
Î Switch off power supply and dis-
connect the device from power
supply before working on the de-
vice or the cables connected!
Relay allocation:
Control 1 for R1 / PWM A
Control 2 for R1 / PWM A
Control 3 for R1 / PWM A
4.5 Menu: VBus
Expert/VBus
In this menu, sensors and relays can be allocated to the
channels of a SDFK or SD6 connected.
Expert/VBus/Options
Selection: SDFK, SD6
Factory setting: -
Activate the corresponding VBus
®
package (SDFK, SD6) in
the Options menu.
Expert/VBus/SDFK/Channel 1 (...4)
Adjustment range: S1...S10 (channel 1... 3), R1...7 (channel 4)
Factory setting: -
Allocate the sensors and relays in the sub-menus of the
SDFK and SD6 channels.
Expert/VBus/SD6/Channel 1 (...6)
Adjustment range: S1...S10 (channel 1... 6), R1...7 (channel
1... 6), WMZ (only the internal calorimeter can be allo-
cated to channel 6)
Factory setting: -
manual operation/All Relays
manual operation/Relay 1 (...7)
selection: Off, Min, Auto, Max
factory setting: Auto
In this menu, individual or all relays can be switched-on
(relay test), switched-off, or set into automatic mode.
4.6 Menu: Manual mode
