Resol DeltaSol E User Manual

Abbreviations - relay
relay denomination
pump col. 1 (2) solar pump collector eld 1-2
Solar Pumpe Sp 1-4 solar pump store 1-4
2 PV St 1-4 2-port valve store 1-4
3 PV St 1-3 3-port valvel store 1-3
func. bl. 1-5 function block 1-5
HSE protetion against legionella
bypass bypass-circuit
cooling func. cooling function
store load. store loading
par. relay parallel relay
ext. HE exteral heat exchanger
message rel. message relay
AH suppress. afterheating suppression
HC-afterheat. heating circuit afterheating
HC-pump heating circuit pump
HC-Mi open heating circuit mixer open
HC-Mi closed heating circuit mixer closed
Load p. TDHW DHW heating loading pump or
3-port valve respectively
DeltaSol
®
E
© RESOL 20160310 DeltaSol_E_V2.monen.indd
25 |
4. Functions and options
4.1 Menu: Solar
Hydraulic variants:
Solar/Options/loading
adjustment range: 1 … 4
factory setting:: 1
Many hydraulic variants distinguish between pump and
valve control e.g. for multiple stores. The adjustment has to
be carried out in accordance with the overview of the ba-
sic systems with their hydraulic variants (see 3.2). Broadly
speaking, variants with pumps allow speed control, variants
with valves do not and will automatically set the minimum
speed to 100%.
System:
Solar/Options/System
adjustment range: 1 … 7
factory setting: 1
Select the appropriate basic system (see 3.2).
Note:
Select the basic system rst, because the subsequent selec-
tion of a new system will reset all other adjustments to the
factory settings.
Alternatively to the basic system and hydraulic variant, one
of the 30 pre-programmed schemes can be selected.
If a new scheme is selected subsequently, all other adjust-
ments will be reset to the factory settings!.
Schematic:
Solar/Options/schematic
adjustment range: 000 … 030
factory setting: 000
