Retsch AS 200 - Feed Grain Size Specifications; Payload Capacity

Technical Data
13
Mesh size
Max. feed quantity
Max. permitted oversize material
according to DIN 66165
25 µm
14 cm
3
7 cm
3
45 µm
20 cm
3
10 cm
3
63 µm
26 cm
3
13 cm
3
125 µm
38 cm
3
19 cm
3
250 µm
58 cm
3
29 cm
3
500 µm
88 cm
3
44 cm
3
1 mm
126 cm
3
63 cm
3
2 mm
220 cm
3
110 cm
3
4 mm
346 cm
3
173 cm
3
8 mm
566 cm
3
283 cm
3
3.8 Feed Grain Size
Traditional dry sieving is performed in the particle size range of 40 µm to 125 mm. By means of
sieving aids or with wet sieving the measurement range can be extended to 20 µm. The
maximum feed grain size depends on the sample material, the number and aperture size of the
test sieves and the type of the sieving machine.
Examples for the maximum feed grain size according to DIN 66165 are listed in the following
table:
Mesh size
Max. feed grain size
according to DIN 66165
Mesh size
Max. feed grain size
according to DIN 66165
22 µm
710 µm
4 mm
25 mm
45 µm
1 mm
8 mm
45 mm
63 µm
1.4 mm
16 mm
71 mm
125 µm
2.5 mm
22.4 mm
90 mm
250 µm
4 mm
45 mm
150 mm
500 µm
6 mm
63 mm
180 mm
1 mm
10 mm
90 mm
230 mm
2 mm
16 mm
125 mm
300 mm
The Vibratory Sieve Shaker AS 200 control is designed for the measurement range of 20 µm to
25 mm.
3.9 Payload
 Maximum sample quantity: 3 kg
 Maximum sieve stack weight: 6 kg
 Maximum payload: 9 kg (sample material plus test sieves)
 Maximum sieve stack height: 620 mm
 Maximum number of fractions: 11 (height of test sieves and collecting pan: 50 mm (2")) /
23 (height of test sieves and collecting pan: 25 mm (1"))
3.10 Suitable Sieve Diameters
 Suitable sieve diameters: 100 mm / 150 mm / 200 mm / 203 mm (8")
