The transportation lock consists of two long hexagonal screws (SM) securing the drive through
the sieve plate (ST).
Loosen the hexagonal screws (SM) on both sides of the sieve plate (ST) by means of a
13 mm open-end wrench and remove them.
Keep the transportation lock for later transport.
Remove the protective foil from the adhesive tape located on the underside of the rubber
disc (GM).
Position the rubber disc (GM) centrally on the sieve plate (ST) and press it down firmly.
NOTICE The weight without sieve stack and sieve clamping unit amounts approx. 35 kg. The
device must only be lifted by two people.
