Fig. 5: Close-up of the grinding chamber
6.2 Summary table of device parts
Closes the grinding chamber
Clamping unit for grinding jars
Clamps grinding jar on the support
Support for grinding jars
Support for grinding jar and centring aid
When pressed the machine is switched off immediately
Safety lock for the cover
Support for the pin closing mechanism
Cylinder for pneumatic clamping of grinding jars
When turned the machine is switched on/off
Automatically clamps the grinding jar
