Operating the Device
29
Fig. 13: Filling area of the grinding jar
For the grinding jar and grinding disc:
• Remove the residues of ground material on the grinding jar wall, the inner ring and the disc,
e.g. using a brush.
• Check whether the lid seal has been inserted.
• Close the grinding jar/grinding disc with the lid.
• Slide the grinding jar/grinding disc into the support.
Fig. 14: Inserting the grinding jar
Centre the grinding set in the grinding jar support (MA).
Fig. 15: Centred grinding jar
SC
RE
MW
RS
RZ
MA
*
