Retsch RS 300 - Page 43

Cleaning, Wear and Maintenance
43
Fig. 38: Platform insert made of PU for grinding jar
• Replace the platform insert (MA) after approx. 300 operating hours.
– Order No. 03.143.0071
Fig. 39: Bellows cylinder
• Replace the bellows cylinder (AB) after approx. 200 operating hours.
• Block the supply of compressed air when not using the machine for a long period to extend
the service life of all sealing elements.
– Order No. 03.381.0010
MA
AB
