5.2 Overview table of the parts of the device
Pos: 7.7 /00010 B edienungsanlei tungen Kapitelsa mmlungen/T wister Mill (2011)/ 0015 Zyklon Mi ll Twister Bedie nung/1575 NIR M odul Üb ersichtstabelle d er Geräteteil e @ 3\mod_1288 701369285_9.d oc @ 23918 @ @ 1
Element
Description
Function
A
Filter sack for cyclone
Filters the escaping air
B
Immersion tube
Separates air current from sample material
C
Cyclone cassette
Guides the ground sample to the cyclone
D
Cassette lid
Closes the cassette
E
Hopper
Guides the ground sample to the collecting receptacle
F
Sample vessel
Collects the ground sample
G
Splash-back protection
Prevents ejection of the sample material
H
Fill hopper
Guides the sample material to the grinding chamber
I
Grinding chamber hood
Covers the grinding chamber
J
Grinding chamber hood lock
Locks the grinding chamber
K
Operating panel
START / STOP / speed selection/display
L
Grinding chamber lid
Seals the grinding chamber
M
Locking bolt
Locks the grinding chamber hood
N
Screw cassette lid
Secures the cassette lid
O
Sieve insert
Orifice for particle sizes
P
Grinding ring
Grinding sample through friction
R
Rotor – (twister rotor)
Grinds the sample
S
Rotor screw
Keeps rotor on axis
T
Shim
Secures cassette on the device
U
Sample vessel pressure disc
Clamps the sample vessel
