1 LAYOUT
CS 520 is a two function programmable controller, available in Manual, Closed or Open Loop mode, for the
controlled application of granular solids in snow and ice control.
See Appendix for system layout in detail.
2 MAIN MENUS
When the truck is stopped or no ground speed signal is coming in, the screen below will be shown:
0KMh 11:35:07
SPIN‒M SALT‒C
0% 0kg
GATE: 05
TOTAL
SETUP MISC XXXXX REVS
Conveyor mode
Speed
Spinner
Solid material
System clock
Gate position Solid rate
Keypad functions
Power Switch
Fuse
Power Cable
Serial Cable
Sensor Cable
Two Encoders
with push buttons
Touch Pads
USB Port
Valves Cable
