4
4 SYSTEM CONFIGURATION
If the password is correct or a program key is present, the setup screen below will be shown:
Press up / down arrow to navigate to the different features, the * symbol preceding the line will mark the active
line. Press ENTER to edit / select the settings, some fields may also have a sub menu as indicated by the
‘CHG’ icon. This is for editing the field. (See example of the editing of REGN below).
Press NPAGE to go to the next screen and PPAGE to the former one.
4.1 Setting the Region Name and Truck ID
REGN: To edit the REGION and TRUCK name
Press to switch between region and truck name. Press CHG to start to edit the region or truck name,
Then press FINSH button to quit editing.
4.2 Setting the UNIT
UNIT: To choose the system unit, metric or imperial.
4.3 Authorization method
LOCK: A valid USB programing key or six characters password can be chosen to verify the access to the setup
screen.
4.4 Setting the Time
TIME: Clock time is formatted as: Hour: Minute: Second
4.5 Setting the Date
DATE: is formatted as Month: Day: Year
* REGN: REGION BLST: 60X ALM: 88
UNIT: METRIC SPIN: S&P DI: N/A
LOCK: P000000 MODE: STD DF: 150
TIME: 00:00:00 USER: M+G OS:
M/D/Y: 00-00-00 LIQU: N/A
EXIT NPAGE MISC XXXXX ENTER
* REGN: REGION BLST: 60X ALM: 88
UNIT: METRIC SPIN: S&P DI: N/A
LOCK: P000000 MODE: STD DF: 150
TIME: 00:00:00 USER: M+G OS:
M/D/Y: 00-00-00 LIQU: N/A
CHG NPAGE MISC XXXXX FINSH
To Next Page
