3
Key pads from left to right are for TOTAL, SETUP, MISC, SUBMENU and REVERSE. Pressing the touch
panel pad enters the corresponding menu screen or holding REVS to reverse the conveyor.
TOTAL ---- trip and season totals, data display / save / load / log
SETUP ---- access to all settings of the system
MISC ---- adjust the brightness of screen or driver ID if AVL attached
- ---- go to submenu to do speed simulation, gate adjustment and material change.
REVS ---- to reverse the conveyor
The screen below will show up when system is saving log data automatically, please keep the power on and let
it finish by itself.
3 AUTHORIZATION VERIFICATION
To set up the CS-520, either a security USB or a password is needed according to the setting of LOCK feature
in programming mode. This is to prevent unauthorized personnel from making adjustments to the system.
After pressing the ‘SETUP’ button, the screen changes to “PLS insert USB” or the input of the password. If it is
password verification, the screen below will be shown:
The most right digit stays bright while the rests are dim, pressing the keypads left or right arrows to choose the
digit and the up / down arrow to change character (This also applies to the settings of other features). After that,
press ENTER to confirm the input. The default password is 000000, the user can change this password once in
the setup screen.
Firmware Version Number:
V.X
Please Enter Code
Code: 0 0 0 0 0 0
TOTAL SETUP MISC XXXXX ENTER
======================================
Log is backing up …
Pls keep power on !
=======================================
