2020 rf IDEAS Inc rfIDEAS Configuration Utility User Manual P a g e  54
Image 56: Detecting the Reader
FUNCTION DESCRIPTION
Status The status may display the following:
x Reader not connected Ensure the reader is connected
properly
x Incorrect reader connected The Card Analyzer feature is only
compatible with following WAVE ID Plus Readers 800x1AxU
800x2AxU805x1AxU805x2AxU80081AKU80082AKU80581AU
80582AKU300x1AxU300x2AxU300x1BxU300x2BxU305x1AxU
305x2AxU305x1BxU305x2BxU300x1CxUMXS800x1AxU
NT805x1AxUNTOEM805x2BxULNV80581AKURA805x1AxU
RA
x Reader connected
Learn Card
Press to transition to the Learn Card screen This button becomes active
only when connected to the correct reader
