CROSS
Turn the rotary knob, and select <CROSS>, push the knob to confirm, enter to the menu items as
follows:
Set H total, V total, width and height of each screen according to actual need.
For example, set H total as 3840, V total as 2160, Width 1 as 1920 and Height 1 as 1080, then
Width 3 will be 1920 ( H total <3840> - Width 1 <1920> = Width 3 <1920> ).
Height 2 will be 1080 ( V total <2160> - Height 1 <1080> = Height 2 <1080> ).
As shown in the figure below:
H 2 In/3Out
1. Turn the rotary knob, and select <H 2 In/3 Out>, push the knob to confirm, and enter to the
menu items as follows:
