triggers，indicator lamp will be red（light）.it signifies that signal triggers. If signal
triggers， indicator lamp not light，you should check the corresponding signal sensor、
circuit and interface board.
OUTPUT SIGNAL terminal has 01-32, total of 32 status indicator lamps, and
the interface board OUTPUT SIGNAL terminal Y01 - Y16 one-to-one correspond to
the indicator lamps.Indicator lamp01- OUTPUT SIGNAL Y01(Spindle CW state ，
Spindle CCW state), indicator lamp02- OUTPUT SIGNAL Y02(Spindle Shift 1) ，
indicator lamp03- OUTPUT SIGNAL Y03(Spindle Shift 2) ， indicator lamp04-
OUTPUT SIGNAL Y04(Spindle Shift 3),and other lamps correspond to other
definable signal.
User can change indicator lamp state by pressing“ ”，to realize manually
control output signal.Press“ ”、“ ” to move cursor left and right，and
then press“ ”to change indicator lamp state. For instance：If cursor stop at
indicator lamp 01，press “ ”，indicator lamp lights（get red），spindle on.
