APPENDIX A - EMC TABLES
GUIDANCE AND MANUFACTURER’S DECLARATION
– ELECTROMAGNETIC IMMUNITY
The Hydratherm tank is intended for use in the electromagnetic environment specified
below. The customer or the user of the Hydratherm tank should assure that it is used in
such an environment
Immunity test IEC 60601 test level Compliance level Electromagnetic environment – guidance
Conducted RF
IEC/EN
61000-4-6
Radiated RF
IEC/EN
61000-4-3
3 Vrms
150 kHz to 80 MHz
outside ISM bands
a
10 V/m
80 MHz to 2.5 GHz
3 Vrms
10 V/m
80MHz to 2 .5 G Hz
Portable and mobile RF
communications equipment should
be used no closer to any part of
the E360T-SY-IN Ventilator,
including cables, than the
recommended separation distance
calculated from the equation
applicable to the frequency of the
transmitter.
Recommended separation distance
d = 3,5
d = 1,2
d 3.2=
...
80 MHz to 800 MHz
...
800 MHz to 2.5 GHz
Where P is the maximum output
power rating of the transmitter
in Watts (W) according to the
transmitter manufacturer and d
is the recommended separation
distance in meters (m)
b
.
Field strengths from fixed RF
transmitters, as determined
by an electromagnetic site survey,
c
should be less than the
compliance level in each
frequency range.
Interference may occur in the
vicinity of equipment marked with
the following symbol:
NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation
is affected by absorption and reflection from structures, objects and people.
The ISM (industrial, scientific and medical) bands between 150 kHz and 80 MHz
are 6,765 MHz to 6,795 MHz; 13,553 MHz to 13,567 MHz; 26,957 MHz to 27,283
MHz; and 40,66 MHz to 40,70 MHz.
P
P
6
Vrms
150 kHz to 80 MHz
in ISM bands
a
10 Vrms
Testing additionally done at frequencies to
simulate proximity to wireless transmitters
d
a
d = 1,2
P
18
