Richmar HydraThermDT - Draining Instructions

DRAIN INSTRUCTIONS
10
WARNING
ALWAYS unplug the unit from the electrical outlet when cleaning the unit.
ALWAYS allow the heating unit to cool down before moving. It is NOT recommended to
move the tank when filled with water, as it can cause water to overflow out of the tank
and possibly cause damage to the electrical outlet and your facility. ALWAYS use
NOTE: If the only way
to drain the tank is to move it while full, it is strongly suggested to have 2 people grip the
tank, each
using the side handle, and carefully move the tank where it can be drained.
The HydraTherm DT unit should take approximately 10 minutes to drain:
1. Connect hose to the male connection on the back of the tank with
dark grey portion of hose connection facing up and push until
you hear the button click into place, as shown in Figure 3.
2. Let hose drain down into a sink until tank is empty.
3. Remove hose by pressing down on dark grey portion of hose until you feel
a click and then pull hose way from back of tank as shown in Figure 4.
4. Remove packs and finned rack.
5. Remove drain filter at bottom of tank to rinse out any debris caught
in the filter or bottom of tank. Wipe tank clean of any debris.
Figure 3.
Figure 4.
drain hose to drain unit, DO NOT dump water from top of unit.
