Placing Originals
13
1
Placing Originals in the ARDF
Place originals in the ARDF.
Settings should be made when placing custom size originals.
❖ When placing custom size originals:
See p.14 “Specifying the Original Size When a Paper Tray is Selected” and
p.17 “Specifying the Original Size When the Bypass Tray is Selected”.
❖ ARDF
A Adjust the document guide to the original size.
B Set the aligned originals face up into the ARDF.
Do not stack originals beyond the limit mark.
The first page should be on the top.
Be sure not to place originals or other objects on the top cover. Doing so may
cause a malfunction.
1 Limit mark
2 Document guide
ARC011S
ARC023S
To Next Page
