Removing Misfed Paper
139
When “Remove Misfeed B:Fusing Unit”
Appears
A If the 2 tray finisher or the booklet finisher is installed, detach it from the
printer.
p.37 “Detaching the SR960 (2 Tray Finisher)”
p.38 “Detaching the SR950 (Booklet Finisher)”
B If the duplex unit is installed, open the duplex reversal unit.
p.38 “Opening and Closing the Duplex Reversal Unit”
C If the output tray is attached to the printer, raise it in the direction of the
arrow ( ), and then remove it ( ).
D Slowly pull out the upper left cover for the printer.
• The inside of the machine becomes very hot. Do not touch parts labelled
“hot surface”. Touching a “hot surface” could result in a burn.
To Next Page
