Replacing Consumables and Maintenance Kit
45
Replacing the Photoconductor Unit
If “Replace Black PCU (Type F)” appears on the display, replace the black pho-
toconductor unit.
If “Replace Color PCU (Type A)” appears on the display, replace the three color
photoconductor units.
❒ The replacement procedure for the third photoconductor unit from the top left
will be described. The procedure is the same for all four photoconductor units.
A Turn off the power, and then unplug the power cable.
B Slowly open the front cover of the printer, remove the green screwdriv-
er.
p.36 “Using the Screwdriver”
C Turn the green lever counterclockwise.
Replace Black
PCU (Type F)
Replace Color
PCU (Type A)
To Next Page
